Product Name: Pharmacy Refrigerator
Model No: PR400
Refrigerator for preserving pharmaceutical products
This refrigerator has been designed in response to the precise requirements
of medical analysis for preserving temperature-sensitive products.
The
latest generation of equipment moreover complies with the SILVER and GOLD safety
standard. 85-95 mm thick insulation with K less than or equal to 0.35W /m2.K
guarantees low energy consumption. The very thick lockable outer door opens
through 900, the door closes automatically.
All setting and monitoring functions are grouped on the control panel equipped
with a digital display and touchpad. This latest generation refrigerator is
equipped with a single RS 485 interface enabling the refrigerator or freezer to
be connected to a computer. All the control and monitoring functions can
consequently be provided using a computer with special software.
The compressor is distinguished by its excellent performance, low noise level
(<60dB) and minimal vibration. The RILSAN shelves promote the circulation of
cold air inside the refrigerator. The electronic management system guarantees
that the preset temperature is constantly maintained. The operating temperature
can be set as required, as can the WARM and COLD alarm points. Two sensors
located inside the unit constantly record the temperature, which is displayed on
the control panel and transmitted to the electronic control system and graphic
temperature recorder respectively. Any temperature deviations are therefore
immediately detected.
The stainless steel interior provides optimal hygienic conditions and great
sturdiness. The refrigerants used do not contain CFCs or HCFCs. Access to the mechanical equipment is easy and allows convenient
cleaning.
Gross Storage Capacity: 489 litres
Material |
|
|
|
Cabinet Insulation (mm) |
85 bis 95 |
|
|
External Material |
Powder painted steel |
|
|
Internal Material |
Stainless steel |
|
|
Volumes |
|
|
|
Gross Volume |
489 l |
|
|
Net Volume |
395 l |
|
|
Outside Dimensions |
|
|
|
Height x Width x Depth (mm) |
1950 x 850 x 785 |
|
|
Net Weight |
202 kgs |
|
|
Inner Dimensions |
|
|
|
Height x Width x Depth (mm) |
1300 x 680 x 553 |
|
|
Ship Dimensions with Ocean (wood) packing |
|
|
|
Height x Width x Depth (mm) |
2130 x 900 x 970 |
|
|
Gross Weight |
269 kgs |
|
|
Temperature Set Range |
|
|
|
Temp Set Point *(amb temp) |
+40C bis +150C |
|
|
Preset "Warm Alarm" |
Set point +20C |
|
|
Preset "Cold Alarm" |
Set point -20C |
|
|
* The amb. temperature must be always be 5K higher than the Set Point.
